GFRG-HIS
Fiberglass-Reinforced Gypsum Access Door
Screwdriver cylinder cam-latch , european Type Hinge, square corners
Gypsum-based material blends in perfectly with drywall surface once painted. The GFRG is specially designed with square corners for a smooth finish.
Technical specifications and dimensions
- Material
Lightweight fiberglass-reinforced gypsum
- Hinge
European Type Hinge
- Locking mechanism
Screwdriver cylinder cam-latch
- Flange
No flange
- Frame
3" frame, made of fiberglass-reinforced gypsum
- Rough opening
Door sizes + 6 " or + 150mm
- Finish
Square corners (radius finish). To be primed and painted on site.
- Packaging
Individually wrapped, 1 door per box
| Dimensions (Inches) | Dimensions (Millimeters) | Weight (LBS) | Weight (KG) |
|---|---|---|---|
| * 9 X 9 | 229 X 229 | 12 | 5.44 |
| * 12 X 12 | 304 X 304 | 15 | 6.8 |
| * 16 X 16 | 406 X 406 | 17 | 7.71 |
| * 18 X 18 | 457 X 457 | 18 | 8.17 |
| * 24 X 24 | 609 X 609 | 22 | 10 |
Technical drawings
Technical documentation
- Technical data sheet
- MasterSpec
Availability
We maintain an inventory of over 42 popular sizes of access panels in our warehouses across North America, ready for next-day delivery or pickup. Refer to the size chart labels to check availability. If not in stock, we can manufacture it in 15 business days.
- Stocked in Montreal
- Stocked in Montreal & USA
- Not in stock. 15 days lead-time.
| Dimensions | Product SKU |
|---|---|
| 9 X 9 | GFRG-PUR-09X09-00-4 |
| 12 X 12 | GFRG-PUR-12X12-00-4 |
| 16 X 16 | GFRG-PUR-16X16-00-4 |
| 18 X 18 | GFRG-PUR-18X18-00-4 |
| 24 X 24 | GFRG-PUR-24X24-00-4 |
