AHD-60-110

Flush Universal Access Door with Exposed Flange

screwdriver-operated cam latch, piano hinge, gasket

Designed for quick and easy installation on non-rated walls and ceilings. The piano hinge and the gasket are used to reduce airflow between the panel and the frame.

  • Installation Walls and ceilings
  • Material Cold rolled steel
  • Locking mechanism Screwdriver-operated cam latch
  • Hinge Piano hinge
  • Flange Exposed flange
  • Size Other sizes available upon request

Quantity

Technical specifications and dimensions

  • Material

    16-gauge cold rolled steel.

  • Hinge

    Hot rolled and stamped steel continuous piano hinge. Hinge location: Hinges must be located on the second dimension (height).

  • Locking mechanism

    Screwdriver-operated cam latch in cold rolled steel.

  • Flange

    1" exposed flange, made of cold rolled steel.

  • Frame

    1 ½" in depth, made of cold rolled steel.

  • Rough opening

    Door sizes + ¼ " or + 6mm.

  • Gasketing

    Neoprene around perimeter of door frame.

  • Finish

    High quality white powder coat primer.

  • Packaging

    Individually wrapped, 1 door per box.

Contact us
Dimensions (Inches)Dimensions (Millimeters)Weight (LBS)Weight (KG)Number of locks
* 6 x 6152 x 1522.61.21
* 8 x 8203 x 2033.61.61
* 8 x 12203 x 3054.82.21
* 10 x 10254 x 2544.82.21
* 12 x 12305 x 3056.12.81
* 12 x 16305 x 4067.63.41
* 12 x 18305 x 4578.63.91
* 12 x 24305 x 61010.74.91
* 14 x 14356 x 3567.63.41
* 16 x 16406 x 4069.24.21
* 18 x 18457 x 45711.25.11
* 18 x 24457 x 61013.96.31
* 20 x 20508 x 50813.15.91
* 22 x 22559 x 55915.47.01
* 22 X 30559 x 76219.58.92
* 22 X 36559 x 91422.810.42
* 24 x 24610 x 61017.57.91
* 24 X 30610 x 76221.79.92
* 24 X 36610 x 91424.411.02
* 24 X 48610 x 121931.414.22
* 30 X 30762 X 76225.611.64
* 36 X 36914 x 91434.215.54
* All dimensions are written in the following order: Width X Height

Technical drawings

Inventory

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

  • Stocked in Montreal
  • Stocked in Montreal & USA
Contact us
Dimensions Product SKU
6 x 6 AHD-06X06-60-110
8 x 8 AHD-08X08-60-110
8 x 12 AHD-08X12-60-110
10 x 10 AHD-10X10-60-110
12 x 12 AHD-12X12-60-110
12 x 16 AHD-12X16-60-110
12 x 18 AHD-12X18-60-110
12 x 24 AHD-12X24-60-110
14 x 14 AHD-14X14-60-110
16 x 16 AHD-16X16-60-110
18 x 18 AHD-18X18-60-110
18 x 24 AHD-18X24-60-110
20 x 20 AHD-20X20-60-110
22 x 22 AHD-22X22-60-110
22 X 30 AHD-22X30-60-110
22 X 36 AHD-22X36-60-110
24 x 24 AHD-24X24-60-110
24 X 30 AHD-24X30-60-110
24 X 36 AHD-24X36-60-110
24 X 48 AHD-24X48-60-110
30 X 30 AHD-30X30-60-110
36 X 36 AHD-36X36-60-110
